Build and run your first Spring Boot app in Visual Studio Code

You know that moment when you clone a Java repository, open it, and nothing happens? No run button, no green ticks, no clue which of the two hundred files is the one that starts. Just a folder.

That gap is almost never about Java being hard. It is about tooling that has not been switched on yet.

In this chapter, we'll switch it on. Two extension packs, one build, one run — and the folder turns into an application you can click around in.

By the end, you will have a Spring Boot web app running on your machine, and you will know which file does what and how the tooling found it.

No terminal gymnastics required.

What You Will Learn

Before we install anything, let's set the target. This is not a tour of every Java feature in the editor. It is the shortest honest path from a cloned folder to a running web page.

In this chapter, you will learn to:

• Install the right tooling: Add the two extension packs that turn Visual Studio Code into a Java and Spring Boot environment, and confirm the surfaces they add.
• Confirm your JDK: Check which Java runtime the project resolved to, and know where to get one if it is missing.
• Read the project structure: Follow a request from the HTML page down to the repository and back, so no file is a mystery.
• Build and run from the editor: Package the project with Maven and start it from the Spring Boot Dashboard, without typing a command.
• Verify it end to end: Add, complete, and delete an item in a real browser, then shut the app down cleanly.

Here is the whole chapter on one line, so you always know where you are.

flowchart LR
    A["Cloned folder"] --> B["Install 2<br/>extension packs"]
    B --> C["Confirm the JDK"]
    C --> D["Read the code<br/>page → controller → service"]
    D --> E["Maven package<br/>BUILD SUCCESS"]
    E --> F["Run from the<br/>Spring Boot Dashboard"]
    F --> G["Verify in the browser"]

Fig 1: Chapter 1 journey, from an unopened folder to a verified running app.

Problem Framing: Why the Tooling Comes First

A Java project is not self-describing. The pom.xml knows the dependencies, the JDK knows how to compile, and Spring Boot knows how to start — but none of that is visible until an extension reads it and puts it on screen.

Install the tooling first and the project explains itself. Skip it, and you end up reading build files by hand to work out what should have been a button.

Try this

Compare two ways of starting. In the first, you open a terminal, guess at a Maven command, and read a wall of log output. In the second, you install two packs, and the editor tells you the runtime it picked, the goals it can run, and the app it can start. The second one scales to a team, because the next person sees exactly the same surfaces.

Prerequisites

A quick readiness check. Most first-run friction here comes from a missing runtime, not from the framework.

• A cloned copy of the sample: Clone microsoft/github-copilot-java-mcp-demo and open the folder in Visual Studio Code.
• Visual Studio Code: Installed and up to date, so extension installation and commands behave as described.
• A Java Development Kit: JDK 25. If you do not have one, the first exercise covers where to get it without leaving the editor.
• No Java extensions yet: Leave the Extension Pack for Java and the Spring Boot Extension Pack uninstalled, because this chapter installs them.

Maven does not need to be installed separately. The repository ships the Maven Wrapper, and the extension pack drives it for you.

Expected warnings: The Maven build prints a Mockito self-attach notice and dynamic-agent warnings, and startup prints three BeanPostProcessorChecker warnings about the MCP annotation scanner. All of them are normal. Wait for BUILD SUCCESS and the started message instead of reacting to them.

What Is the Extension Pack for Java?

The Extension Pack for Java is a Microsoft-published bundle that gives Visual Studio Code full Java support in one install. Instead of picking extensions one at a time and hoping they agree with each other, you get one pack that covers the whole loop.

• Language support: Completion, navigation, refactoring, and diagnostics from the Java language server.
• Debugging: Breakpoints, stepping, and variable inspection for any Java process the editor launches.
• Maven: A Maven view in the Explorer that reads pom.xml and exposes the build lifecycle.
• Project management: A Java Projects view that shows sources, dependencies, and the resolved JDK.
• Testing: Test discovery and a run surface in the Testing view.

The Spring Boot Extension Pack sits on top of that and adds Spring awareness: Spring Boot Tools for Spring-aware editing of configuration and mapping code, and the Spring Boot Dashboard for running, stopping, and inspecting the application.

Fig 2: Searching the Extensions view surfaces both packs used in this chapter.

Exercise - install the tooling

Let's get both packs installed and confirm they are working before touching any code.

1. Select the Extensions button in the Activity Bar, search for Extension Pack for Java, open the result, and select Install.
2. Wait for the Opening Java Projects notification to appear and finish. The pack finds the project's pom.xml and starts importing on its own.
3. Confirm the import worked: the Status Bar reads Java: Ready, and the Explorer has gained Java Projects and Maven views.
4. Select View → Command Palette, search for Java: Configure Java Runtime, and run it. On the Project Settings page, stay on Classpath → JDK Runtime and find JDK: JavaSE-25 with its install path below.
5. If you do not have a JDK yet, Download a new JDK... on that tab fetches one without leaving the editor. Otherwise close the tab without selecting Apply Settings.
6. Return to the Extensions view, search for Spring Boot Extension Pack, and install it too. A new Spring Boot Dashboard icon appears in the Activity Bar.

That is the entire setup. Everything from here on is the project itself.

Reading the Project: What the Tooling Just Imported

Now that the editor understands the project, the files are worth a look. The order below follows a single request through the app, which is a far better map than alphabetical order.

The build file

pom.xml is Maven's project definition, and it is the file the Java extension read first. The spring-boot-starter-parent sets the framework version, the coordinates name the project springboot-mcp-demo, and the java.version property is 25 — matching the JDK you just confirmed.

Below that sit four starter dependencies, and between them they decide what the app can do:

• Actuator: Adds health and monitoring endpoints. Chapter 2 uses these.
• WebMVC: Spring Boot 4's name for the Spring Web starter. It brings the embedded web server and request handling.
• Thymeleaf: Renders HTML pages on the server.
• Spring AI MCP server starter: Publishes the app's operations over the Model Context Protocol. Chapter 3 uses this.

The source layout

In the Explorer, expand src → main, then the compacted java\com\example\tododemo row, then resources → templates. Under the base package the code splits into small folders — model, repository, service, web — plus an mcp folder that Chapter 3 covers, and a templates folder holding the HTML page.

The classes, in request order

Browser, controller, service, repository, and back. That is the full round trip, and it is the same path Chapter 2 traces with a debugger.

Exercise - build and run

With the code understood, let's prove it works.

1. In the Explorer, scroll to the Maven section below the file tree and expand it. Expand springboot-mcp-demo → Lifecycle, hover over package, and select its Run button.
2. Wait for BUILD SUCCESS in the Maven-springboot-mcp-demo terminal that opens. The package goal compiles the code, runs the tests, and produces the runnable JAR, so it proves the whole project is sound rather than just that it compiles.
3. Select the Spring Boot Dashboard icon in the Activity Bar, find springboot-mcp-demo, and select its Run action. Startup takes a few seconds.
4. Check the running state and port in the Dashboard, then select Open In Browser to open http://localhost:8080.
5. In the page, enter Prepare the demo and select Add. Select that row's checkbox, then select its Delete button.
6. Return to the Dashboard and select the app's Stop action.

Fig 3: The Dashboard reports the app as running, alongside the port it bound to.

Each of those three browser actions is a full server round trip: Add posts to /todos and redirects, the checkbox posts to the toggle endpoint, and Delete drops the item from the map. The page re-renders every time, which is why the list is always in step with the server.

Fig 4: The running app — TodoController rendered this page from index.html. This is the moment just after Add in step 5, before the row is completed and deleted.

Because this app keeps its todos in memory, stopping the process clears them. That is intentional for a sample, and it means every chapter starts from a clean list.

Quick Question

The Spring Boot Dashboard can start the application on its own. So why does this chapter run a Maven package build first, and why start the app from the Dashboard rather than from a terminal?

Answer

Those are two separate answers. package is the honest build check: it compiles, runs the tests, and produces the artifact, so a green result means the project is sound and not merely syntactically valid — a Run that starts is a much weaker signal. The Dashboard matters for a different reason: it launches the process through Visual Studio Code, which is what lets the editor attach a debugger and populate live views such as Properties and Memory. An app started from a plain terminal runs perfectly well but stays invisible to those views, and that difference shows up as soon as you want to inspect a running request.

What's Next

You now have a working Java and Spring Boot setup, a project you can navigate, and an application you can start and stop from the editor. That is the foundation every later chapter assumes.

In Chapter 2, Debug and Inspect a Spring Boot Request, we'll stop trusting the browser and start inspecting the process. You'll set a breakpoint on the exact line where the web layer hands off to the service, step through the call, and watch the repository assign an id — then check the app's health and memory while it is still running.

Learn more

• Java in Visual Studio Code — the product-level guide to the surfaces used here.
• Extension Pack for Java on the Marketplace — what the pack installs and why.
• Spring Boot reference documentation — starters, auto-configuration, and the application lifecycle.
• Maven build lifecycle — what package actually runs.
• Demo source on GitHub — the sample used in every chapter.

Chapter 1 of 4 · Next: Debug and Inspect a Spring Boot Request
